Features listed below are subject to change as the USA version of this saw may have slight variations.
CS-7310PW Features
- 73.5cc professional-grade, 2-stroke engine for outstanding performance
- Wrap Handle
- Automatic, adjustable clutch-driven oiler for reduced oil consumption
- Decompression valve for easier starter rope pulling
- Dual bumper spikes for more control while cutting
- Centrifugal separation dust-free system reducing maintenance intervals
- G-Force Engine Air Pre-Cleaner™ for reduced filter maintenance
- Translucent fuel tank for quick fuel level checks
- Magnesium starter housing disperses heat and is stronger
- Dropout prevention nuts so bar nuts aren't lost during service
- Plastic rolling chain catcher gives additional protection to user and chain
- High Torque / High RPM Engine for heavy duty service
CS-7310PW Specifications
| Engine Displacement (cc) |
73.5
|
Oil Capacity (fl oz) |
12
|
| Engine Displacement (cu in) |
4.49
|
Dry Weight (lbs)1
|
14.9
|
| Starting System |
Standard |
Sprocket Cover |
Magnesium |
| Ignition System |
Digital |
Bar Type |
PowerMatch |
| Carburetor |
Butterfly-Valve Diaphragm (without Purge Pump) |
Sprocket Type |
Rim |
| Oiling System |
Automatic/Adjustable (Clutch-Driven) |
Wrap Handle |
Aluminum w/ Rubber |
| Vibration Reduction System |
Standard |
Consumer Warranty |
5 years |
| Available Bar Lengths (in) |
20, 24, 28, 32 |
Commercial Warranty |
1 years |
| Fuel Capacity (fl. oz.) |
27 |
|
|
