KEY FEATURES
- The Cub Cadet XT1 LT50 FAB is powered by a 24 hp KOHLER 7000 Series twin cylinder engine.
- 50-inch fabricated, 11-gauge, triple-blade AeroForce™ deck design that optimizes airflow and maximizes suction to reduce clumping during discharge and improves bagging performance while delivering the pristine Cub Cadet Signature Cut™.
- Optimized steering system for responsive handling gives a 16-inch turn radius a zero-turn feel.
FEATURES
- Hydrostatic: Hydrostatic transmission for smooth clutchless operation with no shifting. Just push the pedal and go.
- Ride with Comfort: Adjustable cut-and-sew high back seat with a 10° incline and slide slope provides elite comfort for an unrivaled mowing experience.
- More Power: A Kohler 7000 Series twin-cylinder engine delivers high-performance power to tackle your yard.
- AeroForce™ Cutting Deck: A heavy-duty fabricated AeroForce™ deck cutting system means fewer clumps, finer clippings and increased evenness.
- Durability: Cast iron front pivot bar provides added durability and rugged performance.
- Strong Warranty: Backed by a 3-year no hour limit warranty, 5-year frame warranty and lifetime limited fabricated deck shell warranty.
- Unmatched Support?: An experienced national dealer network delivers dedicated personal owner support, seven days a week.?
ENGINE
- Engine Brand: Kohler®
- Engine Model: 7000 Series
- Engine Model Number: KT735
- Engine Displacement: 725cc
- Engine Output: 24HP
- Starter Type: Electric
- Fuel Tank Capacity: 3.0 gal. US (11.36 L)
- Cylinders: Twin
- Engine Start: Ignition Key
- Engine Oil Capacity: 2.0 qt. US (1.89 L)
- Lubrication: Fully pressurized
- Charging System: 12 amp regulated
- Fuel Gauge: No
- Governor: Mechanical
- Choke: Choke-a-matic
- Air Filter: Dual element
- Oil Filter: Yes
- Fuel Delivery: Carburetor
BATTERY
- Battery: 230 CCA
- Battery Type: AGM (Absorbent Glass Mat)
- Battery Voltage: 12V
DRIVE SYSTEM
- Transmission: Tuff Torq® K46
- Forward Speed: 5.5 MPH / 8.6 km/h
- Reverse Speed: 3 MPH / 4.8 km/h
- Rear Axle: 3/4"
- Drive System: Hydrostatic
- Transmission Control: Foot Pedal
- Transmission Housing: Aluminum
- Rear Differential Lock: No
CUTTING DECK
- Deck Cutting Width: 50 in
- Deck Wash: Yes
- Deck Material: 11-gauge steel
- Deck Engagement (PTO): Electric
- Deck Construction: Fabricated
- Blade(s): Three
- Deck Lift: Manual
- Cutting Height Range: 1" - 4"
- Anti-Scalping: Four gauge wheels plus roller
- Deck Positions: 12
WARRANTY
- Warranty: 3-year unlimited hours
- Frame Warranty: 5-year unlimited hours
- Front Axle Warranty: 5-year unlimited hours
- Deck Shell Warranty: Lifetime limited
- Commercial Warranty: No
CHASSIS
- Frame: Robotically welded
- Turning Radius: 16"
- Bumper: No
- Rear Tow Hitch: Yes
- Corrosion Protection: Yes
- Front Pivot Bar: Cast iron
CONTROLS
- Cruise Control: Yes
- Brakes: Disc
COMFORT
- Seat Type: 15" high-back
- Armrests: No
- Seat Adjustment: Lever
- Floor Mats: Rubber
WHEELS
- Bearing Type: Poly Bushing
- Rear Tires: 20"x 8"-8"
- Front Tires: 15"x 6"-6"
- Tire Tread: Turf Saver
ADDITIONAL SPECIFICATIONS
- Mulch Kit: Available Separately
- Headlight(s): Dual-LED
- Cup Holder: Yes
- Operator Presence System: Yes
